Export Functions of Template Libraries

Export functions are the interface functions of template libraries, which can be called by strategies that reference the template library.

Examples

• Different programming languages have different formats for writing template libraries. The following are example codes for declaring and implementing export functions in template libraries:

  • javascript
  • python
  • cpp


      javascript


  /*
  -- 策略引用该模板以后直接用 $.Test() 调用此方法
  -- main 函数在策略中不会触发, 只做为模板调试的入口
  */
  $.Test = function() {
      Log('Test')
  }

  function main() {
      $.Test()
  }



      python


  def Test():
      Log("template call")

  # 导出Test函数, 主策略可以通过ext.Test()调用
  ext.Test = Test


      c++


  // 策略引用该模板以后直接用 ext::Test() 调用此方法
  void Test() {
      Log("template call");
  }

• Strategies written in Blockly visual mode can implement library functions through JavaScript language template libraries. Please use the following format.


              javascript


  /*blockly
      {
          "type": "ext_testA",
          "message0": "testA|testA",
          "template": "function(){return 99;}()",
          "order": "ORDER_ATOMIC",
          "output": "Number"
      },{
          "type": "ext_MA",
          "message0": "MA 周期 %1| MA Period %1",
          "args0": [{
              "type": "input_value",
              "check": "Number"
          }],
          "template": "(function(){var r = exchange.GetRecords(); return (!r || r.length < %1) ? false : TA.MA(r, %1); })()",
          "order": "ORDER_ATOMIC",
          "output": null,
          "colour": 85
      }
  */


Template Library Parameters

Template libraries can also set their own interface parameters. Template library parameters are used as global variables in the template library code.

For example, we set a template library parameter:

Examples

• Template library code for testing the param1 parameter:

  • javascript
  • python
  • cpp


      javascript


  $.SetParam1 = function(p1) {
      param1 = p1
  }

  $.GetParam1 = function() {
      Log("param1:", param1)
      return param1
  }


      python


  def SetParam1(p1):
      global param1
      param1 = p1

  def GetParam1():
      Log("param1:", param1)
      return param1

  ext.SetParam1 = SetParam1
  ext.GetParam1 = GetParam1


      c++


  void SetParam1(float p1) {
      param1 = p1;
  }

  float GetParam1() {
      Log("param1:", param1);
      return param1;
  }

• Strategy code referencing the above template library example, using the template library's exported functions to get parameter param1 and modify parameter param1.

  • javascript
  • python
  • cpp


      javascript


  function main () {
      Log("Calling $.GetParam1:", $.GetParam1())
      Log("Calling $.SetParam1:", "#FF0000")
      $.SetParam1(20)
      Log("Calling $.GetParam1:", $.GetParam1())
  }


      python


  def main():
      Log("Calling ext.GetParam1:", ext.GetParam1())
      Log("Calling ext.SetParam1:", "#FF0000")
      ext.SetParam1(20)
      Log("Calling ext.GetParam1:", ext.GetParam1())



      c++


  void main() {
      Log("Calling ext::GetParam1:", ext::GetParam1());
      Log("Calling ext::SetParam1:", "#FF0000");
      ext::SetParam1(20);
      Log("Calling ext::GetParam1:", ext::GetParam1());
  }


Reference Template Library

When a strategy references a template library, the currently logged-in FMZ Quant Trading Platform account must have available template libraries in its strategy library. On the Strategy Edit Page, check the templates you need to reference in the Template section, then save the strategy to complete the reference.
